高阳东(1975-),男,山东黄县人,高级工程师,主要从事海洋油气勘探与开发研究.E-mail:gaoyd@cnooc.com.cn. |
收稿日期: 2021-01-18
修回日期: 2021-03-12
网络出版日期: 2021-04-27
Cenozoic sedimentary evolution and its geological significance for hydrocarbon exploration in the northern South China Sea
Received date: 2021-01-18
Revised date: 2021-03-12
Online published: 2021-04-27
南海北部新生代海陆变迁过程对北部陆缘沉积盆地的沉积充填方式及油气地质特征具有重要的控制作用。基于最新大洋钻探研究成果,结合盆地内已有资料,研究南海北部海相沉积的形成过程,探讨其油气地质意义,可为未来油气资源勘探开发提供依据。受南海洋盆扩张过程的控制,南海北部盆地新生代接受海侵过程总体表现为东早西晚、南早北晚的特点。初始海侵发生在南海东部的台西南盆地始新世,而南海西部的莺歌海盆地则发生在晚渐新世。IODP367/368航次揭示,南海盆地初始海侵期发生在约34 Ma,为南海洋盆初始打开时期;大规模海侵引起的沉积环境剧变期对应于南海西南次海盆打开的时期(约23 Ma),是南海扩张的鼎盛时期。海陆变迁过程控制了海陆过渡相、海相烃源岩及储层在盆地中的分布,南海北部各盆地海相烃源岩层系具有由东向西逐步变年轻的规律,与区域内由东向西逐步接受海侵的方向相一致。区域海平面变化受到南海海盆扩张过程及全球海平面变化的综合影响,使南海碳酸盐岩台地的发育时间也存在东早西晚、南早北晚的特点,构成南海北部自生自储式的油气藏类型。海陆变迁控制了不同盆地的沉积充填方式,奠定了海相沉积的油气资源物质基础。南海北部生储盖组合在横向上受控于物源供给及海陆变迁造成的沉积环境演变,纵向上主要受控于南海构造演化及区域海平面升降。
高阳东 , 向绪洪 , 张向涛 . 南海北部新生代沉积演变及其油气地质意义[J]. 天然气地球科学, 2021 , 32(5) : 645 -656 . DOI: 10.11764/j.issn.1672-1926.2021.03.008
During the Cenozoic, sea-land transition processes have important controlling effect on the depositional and petroleum geological characteristics of the northern South China Sea sedimentary basins. Based on the latest research results of IODP and the existing data in the basin, researches about the formation process of marine sediments in the northern South China Sea are carried out, and its geological significance for hydrocarbon exploration is carried out, in order to provide a basis for the future exploration and development of oil and gas resources. With the seafloor expansion process, the northern South China Sea correspondingly showed a westward and southward marine transgression during the Cenozoic. In Eocene, marine transgression firstly occurred in the Taixinan Basin in the eastern South China Sea. Later it was not until Late Oligocene that marine transgression occurred in the Yinggehai Basin of the western South China Sea. IODP 367/368 site revealed that the initial marine transgression occurred at ca. 34 Ma, and coincided with the start of the South China sea seafloor spreading. The southwest sub-basin of the South China Sea was originally formed at ca. 23 Ma, and large-scale transgression with drastic sedimentary environment changes took place during this time. Marine source rock strata in the northern South China Sea basins gradually get younger from east to west, which is also consistent with the westward marine transgression processes. Under the comprehensive impacts of both South China Sea expansion and global sea level changes, carbonate platforms also evolved from east to west, and from south to north, and formed a self-generation and self-storage oil and gas reservoir pattern in the northern South China Sea. Conclusively, sea-land transition has controlled sedimentary infilling processes within different basins, which were formed as material foundation for petroleum resources. Horizontally, the northern South China Sea source-reservoir-cap assemblage was dominated by provenances and sedimentary environment evolution. Vertically, on the other hand, it was mainly controlled by regional tectonic events and sea level changes.
1 |
朱伟林.南海北部大陆边缘盆地天然气地质[M].北京:石油工业出版社,2007.
ZHU W L. Gas Geology in Marginal Basins of the Northern South China Sea[M].Beijing:Petroleum Industry Press, 2007.
|
2 |
张功成,米立军,吴时国,等.深水区—南海北部大陆边缘盆地油气勘探新领域[J].石油学报,2007,28(2):15-21.
ZHANG G C, MI L J, WU S G, et al. Deepwater area-the new prospecting targets of northern continental margin of South China Sea[J]. Acta Petrolei Sinica,2007,28(2):15-21.
|
3 |
张功成,王璞珺,吴景富,等.边缘海构造旋回:南海演化的新模式[J].地学前缘,2015,22(3):27-37.
ZHANG G C, WANG P J, WU J F, et al. Tectonic cycle of marginal oceanic basin: A new evolution model of the South China Sea[J]. Earth Science Frontiers,2015,22(3): 27-37.
|
4 |
朱伟林,张功成,高乐.南海北部大陆边缘盆地油气地质特征与勘探方向[J].石油学报,2008,29(1):1-9.
ZHU W L, ZHANG G C, GAO L. Geological characteristics and exploration objectives of hydrocarbons in the northern continental margin basin of South China Sea[J]. Acta Petrolei Sinica,2008,29(1):1-9.
|
5 |
ZHANG H, SHAO L, ZHANG G C, et al. The response of Cenozoic sedimentary evolution coupled with the formation of the South China Sea[J]. Geological Journal, 2020,55(10): 6989-7010.
|
6 |
SHAO L, CUI Y C, STATTEGGER K, et al. Drainage control of Eocene to Miocene sedimentary records in the southeastern margin of Eurasian Plate[J]. Geological Society of America Bulletin,2019,131(3-4):461-478.
|
7 |
HURCHISON C. Marginal basin evolution: The southern South China Sea[J].Marine and Petroleum Geology,2004,21(9):1129-1148.
|
8 |
李三忠,索艳慧,刘鑫,等.南海的盆地群与盆地动力学[J].海洋地质与第四纪地质,2012,32(6):55-78.
LI S Z, SUO H Y, LIU X, et al. Basin dynamics and basin groups of the South China Sea[J]. Marine Geology & Quaternary Geology,2012,32(6):55-78.
|
9 |
SHAO L, CAO L C, PANG X, et al. Detrital zircon provenance of the Paleogene syn-rift sediments in the northern South China Sea[J]. Geochemistry, Geophysics, Geosystems,2016,17(2):255-269.
|
10 |
TAPPONNIER P, PELTZER G, ARMIJO R. On the mechanism of collision between India and Asia[C]//COWARD M, RIES A C(eds.). Collision Tectonics. Geological Society of London Special Publications, 1986, 19: 111-157.
|
11 |
HALL R, BREITFELD T. Nature and demise of the Proto-South China Sea[J]. Bulletin of the Geological Society of Malaysia, 2017, 63:61-76.
|
12 |
HUANG C Y, WANG P X, YU M M, et al. Potential role of strike-slip faults in opening up the South China Sea[J]. National Science Review, 2019, 6(5): 891-901.
|
13 |
ZHU W L, CUI Y C, SHAO L, et al. Reinterpretation of the South China Sea Pre-Cenozoic basement and geodynamic implications of the SE Asia: Constraints from combined geological and geophysical records[J]. Acta Oceanologica Sinica. 2020, ID:AOS-2019-11-0286.R1.
|
14 |
WANG P X, HUANG C Y, LIN J, et al. The South China Sea is not a mini-Atlantic: Plate-edge rifting vs intraplate rifting[J]. National Science Review,2019,6(5):902-913.
|
15 |
LARSEN H C, MOHN G, NIRRENGARTEN M, et al. Rapid transition from continental breakup to igneous oceanic crust in the South China Sea[J]. Nature Geoscience, 2018, 11:782-789.
|
16 |
LI C F, LI J B, DING W W. Seismic stratigraphy of the central South China Sea Basin and implications for Neotectonics[J]. Journal of Geophysical Research: Solid Earth,2015,120(3):1377-1399.
|
17 |
邵磊,崔宇驰,乔培军,等.南海北部古河流演变对欧亚大陆东南缘早新生代古地理再造的启示[J].古地理学报,2019,21(2):216-231.
SHAO L, CUI Y C, QIAO P J, et al. Implications on the Early Cenozoic palaeogeographical reconstruction of SE Eurasian margin based on northern South China Sea palaeo-drainage system evolution[J]. Journal of Palaeogeography,2019,21(2):216-231.
|
18 |
孙珍,林间,汪品先,等.国际大洋发现计划IODP367/368/368X航次推动南海国际化海洋科考成果[J].热带海洋学报,2020,39(6):18-29.
SUN Z, LIN J,WANG P X, et al. International collaboration of ocean exploration in the South China Sea enhanced by International Ocean Discovery Program Expeditions 367/368/368x[J]. Journal of Tropical Oceanography,2020,39(6):18-29.
|
19 |
于兴河,李胜利,乔亚蓉,等.南海北部新生代海陆变迁与不同盆地的沉积充填响应[J].古地理学报,2016,18(3):349-366.
YU X H, LI S L, QIAO Y R, et al. The Cenozoic changes of seas and lands and sedimentary filling responses of different basins in northern South China Sea[J]. Journal of Palaeogeography,2016,18(3):349-366.
|
20 |
JIAN Z M, JIN H Y, KAMINSKI M A, et al. Discovery of the marine Eocene in the northern South China Sea[J]. National Science Review, 2019, 6(5):881-885.
|
21 |
HUANG C Y, SHAO L, WANG M H, et al. Benthic foraminiferal fauna and sediment provenance of Eocene syn-rift sequences in Taiwan: Implication for onset of Asian epi-ontinental marginal seas off China coast[J]. Marine Geophysical Research, 2018,40(2):1-17.
|
22 |
SHAO L, MENG A H, LI Q Y, et al. Detrital zircon ages and elemental characteristics of the Eocene sequence in IODP Hole U1435A: Implications for rifting and environmental changes before the opening of the South China Sea[J]. Marine Geology, 2017, 394: 39-51.
|
23 |
邵磊,庞雄,张功成,等.南海北部渐新世末的构造事件[J].地球科学:中国地质大学学报,2009,34(5): 717-724.
SHAO L, PANG X, ZHANG G C, et al. Late Oligocene tectonic event in the northern South China Sea and its implications[J]. Earth Science: Journal of China University of Geosciences,2009, 34(5):717-724.
|
24 |
SHAO L, CUI Y C, QIAO P J, et al. Sea-level changes and carbonate platform evolution of the Xisha Islands(South China Sea) since the Early Miocene[J]. Palaeogeography, Palaeoclimatology, Palaerecology, 2017,485:504-516.
|
25 |
WU J, SUPPE J, LU R, et al. Philippine Sea and East Asian plate tectonics since 52 Ma constrained by new subducted slab reconstruction methods[J]. Journal of Geophysical Research: Solid Earth,2016, 121(6):4670-4741.
|
26 |
吴时国,朱伟林,马永生.南海半封闭边缘海碳酸盐台地兴衰史[J].海洋地质与第四纪地质,2018,38(6): 1-17.
WU S G, ZHU W L, MA Y S. Vicissitude of Cenozoic carbonate platforms in the South China Sea: Sedimentation in semi-closed marginal seas[J] . Marine Geology & Quaternary Geology,2018,38(6):1-17.
|
27 |
梁建设,张功成,王璞珺,等.南海陆缘盆地构造演化与烃源岩特征[J].吉林大学学报:地球科学版, 2013, 43(5):1309-1319.
LIANG J S, ZHANG G C, WANG P J, et al. Tectonic evolution of epicontinental basins in South China Sea and their feature of source rocks[J].Journal of Jilin University: Earth Science Edition,2013,43(5):1309-1319.
|
28 |
米立军,张忠涛,庞雄,等.南海北部陆缘白云凹陷油气富集规律及主控因素[J].石油勘探与开发, 2018,45(5):902-913.
MI L J, ZHANG Z T, PANG X, et al. Main controlling factors of hydrocarbon accumulation in Baiyun Sag at northern continental margin of South China Sea[J]. Petroleum Exploration and Development,2018,45(5): 902-913.
|
29 |
庞雄,任建业,郑金云,等.陆缘地壳强烈拆离薄化作用下的油气地质特征——以南海北部陆缘深水区白云凹陷为例[J].石油勘探与开发,2018,45(1):27-39.
PANG X, REN J Y, ZHENG J Y, et al. Petroleum geology controlled by extensive detachment thinning of continental margin crust: A case study of Baiyun Sag in the deep-water area of northern South China Sea[J]. Petroleum Exploration and Development,2018,45(1):27-39.
|
30 |
CUI Y C, SHAO L, QIAO P J, et al. Upper Miocene-Pliocene provenance evolution of the central Canyon in northwestern South China Sea[J]. Marine Geophysical Research,2019,40(2):223-235.
|
31 |
朱筱敏,葛家旺,赵宏超,等.陆架边缘三角洲研究进展及实例分析[J].沉积学报,2017,35(5):945-957.
ZHU X M, GE J W, ZHAO H C, et al. Development of shelf-edge delta researches and typical case analysis[J]. Acta Sedimentologica Sinica,2017,35(5):945-957.
|
32 |
徐强,王英民,王丹,等.南海白云凹陷深水区渐新世—中新世断阶陆架坡折沉积过程响应[J].沉积学报,2010,28(5):906-914.
XU Q, WANG Y M, WANG D, et al. Sedimentary responses of retreating shelf break from Oligocene to Miocene, in deep water area of Baiyun Depression, South China Sea[J]. Acta Sedimentologica Sinica,2010, 28(5):906-914.
|
33 |
解习农,张成,任建业,等.南海南北大陆边缘盆地构造演化差异性对油气成藏条件控制[J].地球物理学报,2011,54(12):3280-3291.
XIE X N, ZHANG C, REN J Y, et al. Effects of distinct tectonic evolutions on hydrocarbon accumulation in northern and southern continental marginal basins of South China Sea[J]. Chinese Journal of Geophysics, 2011,54(12):3280-3291.
|
34 |
何家雄,李福元,王后金,等.南海北部大陆边缘深水盆地成因机制与油气资源效应[J].海洋地质前沿,2020,36(3):1-11.
HE J X, LI F Y, WANG H J, et al. Genetic mechanism of deepwater basins and their effects on oil and gas resources on the continental margin of the northern South China Sea[J]. Marine Geology Frontiers, 2020, 36(3):1-11.
|
35 |
庞雄,朱明,柳保军,等.南海北部珠江口盆地白云凹陷深水区重力流沉积机理[J].石油学报,2014, 35(4):646-653.
PANG X, ZHU M ,LIU B J, et al. The mechanism of gravity flow deposition in Baiyun Sag deepwater area of the northern South China Sea[J]. Acta Petrolei Sinica,2014,35(4):646-653.
|
36 |
WU S G, YUAN S Q, ZHANG G C, et al. Seismic characteristics of a reef carbonate reservoir and implications for hydrocarbon exploration in deepwater of the Qiongdongnan Basin, northern South China Sea[J]. Marine and Petroleum Geology,2009,26(6):817-823.
|
37 |
吴梦霜,邵磊,庞雄,等.南海北部深水区白垩的发现及其储层意义[J].石油学报,2013,34(S2):32-38.
WU M S,SHAO L,PANG X, et al. Discovery of chalk in deep-water area of the northern South China Sea and its significance of reservoirs[J]. Acta Petrolei Sinica,2013,34(S2):32-38.
|
38 |
李友川,邓运华,张功成,等.南海北部第三系海相烃源岩[J].石油学报,2011,32(2):219-225.
LI Y C, DENG Y H, ZHANG G C, et al. Tertiary marine source rocks in the northern South China Sea[J]. Acta Petrolei Sinica,2011,32(2):219-225.
|
39 |
郝诒纯,陈平富,万晓樵,等.南海北部莺歌海—琼东南盆地晚第三纪层序地层与海平面变化[J].现代地质,2000,14(3):237-245.
HAO Y C, CHEN P F, WAN X Q, et al. Late Tertiary sequence stratigraphy and sea level changes in Yinggehai-Qiongdongnan Basin[J].Geoscience,2000,14(3):237-245.
|
40 |
秦国权.珠江口盆地新生代晚期层序地层划分和海平面变化[J].中国海上油气:地质,2002,16(1): 1-11.
QIN G Q. Division of sequence stratigraphy and sea level changes in the Pearl River Mouth Basin[J].China Offshore Oil and Gas: Geology,2002,16(1): 1-11.
|
41 |
唐晓音,胡圣标,张功成,等.南海北部大陆边缘盆地地热特征与油气富集[J].地球物理学报,2014, 57(2): 572-585.
TANG X Y, HU S B, ZHANG G C, et al. Geothermal characteristics and hydrocarbon accumulation of the northern mariginal basins, South China Sea[J]. Chinese Journal of Geophysics,2014,57(2):572-585.
|
42 |
庞雄,陈长民,彭大钧,等.南海珠江深水扇系统的层序地层学研究[J].地学前缘,2007,14(1):220-229.
PANG X, CHEN C M, PENG D J, et al. Sequence stratigraphy of Pearl River deep-water fan system in the South China Sea[J]. Earth Science Frontiers, 2007, 14(1): 220-229.
|
43 |
鲁毅,崔宇驰,刘新宇,等.中国南海西沙碳酸盐岩台地形成过程及控制因素:来自西科1井的地球化学证据[J].古地理学报,2020,22(6):1197-1208.
LU Y, CUI Y C, LIU X Y, et al. Formation process and controlling factors of carbonate platform in Xisha area, South China Sea: Based on geochemical evidences from Well Xike-1[J]. Journal of Palaeogeography, 2020, 22(6): 1197-1208.
|
44 |
SHAO L, LI Q Y, ZHU W L, et al. Neogene carbonate platform development in the NW South China Sea: Litho-, bio- and chemo-stratigraphic evidence[J]. Marine Geology,2017,385:233-243.
|
/
〈 |
|
〉 |
